Snap Switches 903
9 Pole ON - OFF - ON 3DPT
Rating: 15A 125VAC/10A 250VAC
Insulation Resistance: DC 500V 200MΩ Min.
Contact Resistance: DC2-4V 1A 20MΩ Max.
Withstand Voltage: AC 1500V Min.
Rating: 15A 125VAC/10A 250VAC
Insulation Resistance: DC 500V 200MΩ Min.
Contact Resistance: DC2-4V 1A 20MΩ Max.
Withstand Voltage: AC 1500V Min.
Model :
903
9 Pole ON - OFF - ON 3DPT
Rating: 15A 125VAC/10A 250VAC
Insulation Resistance: DC 500V 200MΩ Min.
Contact Resistance: DC2-4V 1A 20MΩ Max.
Withstand Voltage: AC 1500V Min.
